Samsung VM46B-U LCD Indoor

Display technology

LCD

Display diagonal

116.8 cm (46")

Display resolution

1920 x 1080 pixels

HD type

Full HD

Panel type

IPS

Aspect ratio

16:09

Pixel pitch

0.53 x 0.53 mm

Display brightness

500 cd/m²

Contrast ratio (typical)

1200:01:00

Response time

0.008 s

Viewing angle, horizontal

178°

Viewing angle, vertical

178°

Operating hours (hours/days)

24/7

Pixel frequency

82 MHz

Contrast ratio (dynamic)

45000:1

Horizontal scan range

62.7 - 72.3 kHz

Vertical scan range

57 - 63 Hz

Placement supported

Indoor

Orientation

Horizontal/Vertical

Bezel width (top)

2.25 mm

Bezel width (side)

1.25 mm

Bezel width (bottom)

2.25 mm

VESA mounting

Yes

Panel mounting interface

600 x 400 mm

Panel colour

Black

Product colour

Black

HDMI ports quantity

2

DVI port

Yes

DisplayPorts quantity

1

Ethernet LAN

Yes

Ethernet LAN (RJ-45) ports

1

USB port

Yes

RS-232C

Yes

USB ports quantity

1

HDCP version

2.2

HDCP

Yes

RS-232 output ports

1

RS-232 input ports

1

IR input ports quantity

1

Audio output

Yes

Audio input

Yes

HDMI version

2

DisplayPort version

1.2

Power consumption (typical)

160 W

Energy efficiency class (SDR)

G

Energy consumption (SDR) per 1000 hours

128 kWh

AC input voltage

100 - 240 V

AC input frequency

50 - 60 Hz

Energy efficiency scale

A to G

Harmonized System (HS) code

85285210

Operating temperature (T-T)

0 - 40 °C

Operating relative humidity (H-H)

10 - 90%

Harmonized System (HS) code

85285210

Certification

FCC (USA) Part 15, Subpart B Class ACE (Europe) : EN55032 : 2012 or 2015 　 EN55024:2010 or EN 55035:2017VCCI (Japan) : VCCI CISPR32:2016 Class BKCC/EK (Korea) : Tuner : KN13 / KN20Tunerless : KN22 / KN24BSMI (Taiwan) : CNS13438 ( ITE EMI ) Class A / CNS14336-1 ( ITE Safety ) / CNS15663 (RoHS)C-Tick (Australia) : AS/NZS CISPR32:2015CCC(China) :GB/T9254-2008, GB17625.1-2012GOST(Russia/CIS) : ROCT CISPR 24-2013/ROCT CISPR 22:2005

Width

1022 mm

Depth

69.9 mm

Height

577 mm

Weight

15.7 kg

Package width

1193 mm

Package depth

257 mm

Package height

719 mm

Package weight

22.2 kg
