TP-LINK AX5400 Ceiling Mount Dual-Band Wi-Fi6 AP
In Stock
|
Call For Price
(0808 189 1246)
TP-LINK AX5400 Ceiling Mount Dual-Band Wi-Fi6 AP
Data transmission
Ethernet LAN data rates
2500 Mbit/s
Maximum data transfer rate
5400 Mbit/s
Performance
2.4 GHz
Yes
5 GHz
Yes
Wireless isolation
Yes
Automatic channel selection
Yes
Reset button
Yes
Firmware upgradeable
Yes
Frequency band
2.4 - 5 GHz
Number of users
250 user(s)
Web-based management
Yes
VLAN support
No
Rate limiting
Yes
Quality of Service (QoS) support
Yes
Networking standards
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates
2500 Mbit/s
Certification
CE, FCC, RoHS
Maximum data transfer rate
5400 Mbit/s
MIMO type
Multi User MIMO
MIMO
Yes
Band steering
Yes
Remote Authentication Dial-In User Service (RADIUS)
Yes
Wireless LAN features
Frequency band
2.4 - 5 GHz
Network
Number of users
250 user(s)
Networking standards
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Management features
VLAN support
No
Rate limiting
Yes
Quality of Service (QoS) support
Yes
Firmware upgradeable
Yes
Web-based management
Yes
Features
6 GHz
No
2.4 GHz
Yes
5 GHz
Yes
Wireless isolation
Yes
Automatic channel selection
Yes
Frequency band
2.4 - 5 GHz
Number of users
250 user(s)
VLAN support
No
Rate limiting
Yes
Quality of Service (QoS) support
Yes
Networking standards
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates
2500 Mbit/s
Maximum data transfer rate
5400 Mbit/s
Transmitting power (FCC)
<25 dBm (2.4 GHz); <28 dBm (5 GHz)
Transmitting power (CE)
<20 dBm(2.4 GHz, EIRP); <23 dBm(5 GHz, band1 & band2, EIRP); <30 dBm(5 GHz, band3, EIRP)
Automatic channel scanning
Yes
MIMO type
Multi User MIMO
MIMO
Yes
Band steering
Yes
Maximum data transfer rate (2.4 GHz)
574 Mbit/s
Maximum data transfer rate (5 GHz)
4804 Mbit/s
BeamForming
Yes
Security
Number of SSID supported
16
Access Control List (ACL)
Yes
Remote Authentication Dial-In User Service (RADIUS)
Yes
Service Set Identifier (SSID) features
Multiple SSIDs
Power
Power over Ethernet (PoE)
Yes
Input current
1.5 A
Design
International Protection (IP) code
IP67
Placement
Ceiling, Wall
Product colour
White
Reset button
Yes
LED indicators
Yes
Certification
CE, FCC, RoHS
Antenna
Antenna type
Internal
Antennas quantity
6
Antenna gain level (max)
5 dBi
Antenna direction type
Omni-directional
Technical details
Reset button
Yes
Firmware upgradeable
Yes
Certificates
Certification
CE, FCC, RoHS
Indication
LED indicators
Yes
Software
Automatic channel scanning
Yes
Access Control List (ACL)
Yes
Weight & dimensions
Width
243 mm
Depth
243 mm
Height
64 mm
Package width
302 mm
Package depth
304 mm
Package height
82 mm
Package weight
1.32 kg
Packaging data
Package width
302 mm
Package depth
304 mm
Package height
82 mm
Package weight
1.32 kg
Packaging content
Quantity per pack
1 pc(s)
Logistics data
Quantity per pack
1 pc(s)
