TP-LINK Ceiling Mount Wi-Fi 6 Access Point
In Stock
|
Call For Price
(0808 189 1246)
TP-LINK Ceiling Mount Wi-Fi 6 Access Point
Data transmission
Ethernet LAN data rates
10,100,1000 Mbit/s
Maximum data transfer rate
2976 Mbit/s
Performance
2.4 GHz
Yes
5 GHz
Yes
Flow control support
Yes
Automatic channel selection
Yes
Syslog
Yes
Reset button
Yes
Firmware upgradeable
Yes
Spread spectrum method
OFDMA
Frequency band
2.4 - 5 GHz
Number of users
250 user(s)
Web-based management
Yes
VLAN support
Yes
Rate limiting
Yes
Quality of Service (QoS) support
Yes
Networking standards
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1x, IEEE 802.3at
Ethernet LAN data rates
10,100,1000 Mbit/s
Certification
CE, FCC, RoHS
Maximum data transfer rate
2976 Mbit/s
MIMO type
Multi User MIMO
MIMO
Yes
Band steering
Yes
Airtime Fairness (ATF)
Yes
Wireless LAN features
Frequency band
2.4 - 5 GHz
Network
Spread spectrum method
OFDMA
Number of users
250 user(s)
Networking standards
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1x, IEEE 802.3at
Management features
VLAN support
Yes
Rate limiting
Yes
Quality of Service (QoS) support
Yes
Syslog
Yes
Firmware upgradeable
Yes
Web-based management
Yes
Features
6 GHz
No
2.4 GHz
Yes
5 GHz
Yes
Flow control support
Yes
Automatic channel selection
Yes
Spread spectrum method
OFDMA
Frequency band
2.4 - 5 GHz
Number of users
250 user(s)
VLAN support
Yes
Rate limiting
Yes
Quality of Service (QoS) support
Yes
Networking standards
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1x, IEEE 802.3at
Ethernet LAN data rates
10,100,1000 Mbit/s
Cabling technology
10/100/1000Base-T(X)
Maximum data transfer rate
2976 Mbit/s
Transmitting power (FCC)
<25 dBm (2.4 GHz) <25 dBm (5 GHz)
Transmitting power (CE)
<20 dBm(2.4 GHz, EIRP) <23 dBm(5 GHz, Band1 & Band2, EIRP) <30 dBm(5 GHz, Band3, EIRP)
Automatic channel scanning
Yes
MIMO type
Multi User MIMO
MIMO
Yes
Band steering
Yes
Airtime Fairness (ATF)
Yes
Maximum data transfer rate (2.4 GHz)
574 Mbit/s
Maximum data transfer rate (5 GHz)
2402 Mbit/s
Fit AP mode features
Mesh networking
BeamForming
Yes
Security
Security algorithms
SNMP, SNMPv2, SNMPv3, SSH, WPA-Enterprise, WPA-PSK, WPA2-Enterprise, WPA2-PSK, WPA3-Enterprise, WPA3-PSK
MAC address filtering
Yes
Access Control List (ACL)
Yes
Ports & interfaces
USB 2.0 ports quantity
0
Ethernet LAN (RJ-45) ports
1
DC-in jack
Yes
Cabling technology
10/100/1000Base-T(X)
Power
Power over Ethernet (PoE)
Yes
DC voltage range
12 V
Design
Placement
Ceiling, Wall
Product colour
White
Reset button
Yes
LED indicators
Yes
Certification
CE, FCC, RoHS
Antenna
Antenna type
Internal
Technical details
Reset button
Yes
Firmware upgradeable
Yes
Certificates
Certification
CE, FCC, RoHS
Indication
LED indicators
Yes
Software
Automatic channel scanning
Yes
Access Control List (ACL)
Yes
Weight & dimensions
Width
160 mm
Depth
160 mm
Height
33.6 mm
Packaging data
Quick start guide
Yes
Mounting kit
Yes
Package type
Box
Packaging content
Quick start guide
Yes
Mounting kit
Yes
Quantity per pack
2 pc(s)
Package type
Box
Operational conditions
Operating relative humidity (H-H)
10 - 90%
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-40 - 70 °C
Storage relative humidity (H-H)
5 - 90%
Logistics data
Quantity per pack
2 pc(s)
