Hikvision DS-2CD2387G2H-LIU(2.8MM)(EF)
In Stock
|
£180.55
£216.66 (Inc. VAT)
Hikvision DS-2CD2387G2H-LIU(2.8MM)(EF)
Performance
Infrared (IR) cut-off filter
Yes
Number of languages
33
Languages support
Multi
Type
IP security camera
Connectivity technology
Wired
Placement supported
Indoor & outdoor
Wide Dynamic Range (WDR)
Yes
Day/night mode
Yes
Built-in light
Yes
Dynamic range
130 dB
Design
Form factor
Turret
Product colour
White
Mounting type
Ceiling
Protection features
Dust resistant, Water resistant
International Protection (IP) code
IP67
Housing material
Metal
Camera
Minimum illumination
0 lx
Tilt angle range
0 - 75°
Pan range
0 - 360°
Angle of rotation
360°
Camera shutter speed
1/3 - 1/100000 s
Lens viewing angle, horizontal
108.8°
Lens viewing angle, vertical
56.4°
Lens viewing angle, diagonal
134.3°
Number of Privacy masking areas
4
Progressive scan
Yes
Image sensor
Sensor type
CMOS
Progressive scan
Yes
Optical sensor size
25.4 / 1.8 mm (1 / 1.8")
Number of sensors
1
Lens system
Number of lenses
1
Maximum aperture number
1
Detect distance
89 m
Observe distance
35 m
Recognize distance
17 m
Identify distance
8 m
Fixed focus
Yes
Fixed focal length
2.8 mm
Night vision
Night vision
Yes
Night vision distance
40 m
LED type
IR/White
Infra-red wavelength
850 nm
Video
Noise reduction
Yes
Image quality adjustment
Brightness, Contrast, Saturation, Sharpness
Privacy masking
Yes
Region of Interest (ROI) encoding
Yes
Highlight Compensation (HLC)
Yes
Bit rate control
Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Bit rate
32 Kbps - 16 Mbps
Back Light Compensation (BLC)
Yes
Noise reduction technology
3D noise reduction
Video compression formats
H.264, H.264+, H.265, H.265+, M-JPEG
Maximum resolution
3840 x 2160 pixels
Supported graphics resolutions
640 x 360, 640 x 480 (VGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2688 x 1520, 3200 x 1800, 3840 x 2160
Frame rate
30 fps
Video streaming
Yes
Total megapixels
8 MP
Video recording
Yes
Audio
Signal-to-Noise Ratio (SNR)
52 dB
Built-in microphone
Yes
Audio formats supported
AAC-LC, G.722.1, G.726, MP2L2, MP3, PCM
Sample rates
8 - 48 kHz
Bit rate range
8 - 320 Kbit/s
Network
Bluetooth
No
Ethernet interface type
Fast Ethernet
Quality of Service (QoS) support
Yes
Number of users
32 user(s)
Ethernet LAN
Yes
Wi-Fi
No
Supported network protocols
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets, SRTP, SFTP
Client interoperability
iVMS-4200, Hik-Connect, Hik-Central
User access level
Administrator, Operator, User
Number of simultaneous live view channels
6 channels
Live view
Yes
Storage
Maximum memory card size
512 GB
Card reader integrated
Yes
Built-in HDD
No
Compatible memory cards
MicroSD (TransFlash), MicroSDHC, MicroSDXC
Ports & interfaces
Ethernet LAN (RJ-45) ports
1
Connectivity technology
Wired
Security
Privacy protection
Yes
Video motion detection
Yes
Security algorithms
EAP-LEAP, EAP-MD5, EAP-TLS
IP address filtering
Yes
HTTPS encryption
Yes
Active tampering alarm
Yes
Password protection
Yes
Mirror
Yes
Heartbeat
Yes
Digital watermark
Yes
Pixel counter
Yes
Password reset via email
Yes
Human and vehicle targets classification
Yes
Digest authentication
Yes
Automatic Network Replenishment (ANR)
Yes
Audit log
Yes
Network access storage (NAS)
Yes
Management features
Web-based management
Yes
Reset button
Yes
Behavior analysis
Intrusion detection, Line crossing detection, Region entrance detection, Region exiting detection
Power
Power source type
DC, PoE
Power consumption (max)
6.5 W
Power consumption (Power over Ethernet (PoE))
8 W
DC output voltage
12
DC output current
0.54 A
Operational conditions
Operating temperature (T-T)
-30 - 60 °C
Storage temperature (T-T)
-30 - 60 °C
Operating relative humidity (H-H)
0 - 95%
Storage relative humidity (H-H)
0 - 95%
Weight & dimensions
Height
115.4 mm
Diameter
13.8 cm
Weight
770 g
Package width
170 mm
Package height
16 mm
Package depth
170 mm
Package weight
1.04 kg
Packaging data
Package width
170 mm
Package height
16 mm
Package depth
170 mm
Package weight
1.04 kg
Sustainability
Sustainability compliance
Yes
Compliance certificates
CB, CE, KC, RoHS
Packaging content
Number of cameras
1
Technical details
Lens mount interface
M16
Iris
Yes
Sustainability compliance
Yes
Compliance certificates
CB, CE, KC, RoHS
Other features
Video compression formats
H.264, H.264+, H.265, H.265+, M-JPEG
