Intel Xeon E-2176G processor 3.7 GHz 12 MB Smart Cache Box, Tray
In Stock
|
£335.59
£402.71 (Inc. VAT)
Intel Xeon E-2176G processor 3.7 GHz 12 MB Smart Cache Box, Tray
Processor
Processor base frequency
3.7 GHz
Processor manufacturer
Intel
Cooler included
No
Processor codename
Coffee Lake
Memory bandwidth supported by processor (max)
41.6 GB/s
Thermal Design Power (TDP)
80 W
Processor cache
12 MB
Processor ARK ID
134860
Processor model
E-2176G
Processor threads
12
System bus rate
8 GT/s
Processor operating modes
64-bit
Processor boost frequency
4.7 GHz
Stepping
U0
Bus type
DMI3
Component for
Server/workstation
Processor lithography
14 nm
Processor family
Intel Xeon E
Processor cores
6
Processor socket
LGA 1151 (Socket H4)
Processor code
SR3WS
Processor cache type
Smart Cache
Package type
Box, Tray
Memory
Maximum internal memory supported by processor
128 GB
Memory types supported by processor
DDR4-SDRAM
Memory clock speeds supported by processor
2666 MHz
Memory bandwidth supported by processor (max)
41.6 GB/s
Supported memory types
DDR4-SDRAM
Memory channels
Dual-channel
ECC
Yes
Graphics
Discrete graphics card
No
On-board graphics card outputs supported
Embedded DisplayPort (eDP), DisplayPort, HDMI, DVI
On-board graphics card maximum resolution (DisplayPort)
4096 x 2304 pixels
On-board graphics card ID
0x3E96
On-board graphics card 4K support
Yes
On-board graphics card maximum resolution (eDP - Integrated Flat Panel)
4096 x 2304 pixels
On-board graphics card refresh rate at maximum resolution (HDMI)
24 Hz
On-board graphics card refresh rate at maximum resolution (DisplayPort)
60 Hz
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)
60 Hz
Maximum on-board graphics card memory
128 GB
Number of displays supported (on-board graphics)
3
On-board graphics card maximum resolution (HDMI)
4096 x 2160 pixels
On-board graphics card DirectX version
12.0
On-board graphics card OpenGL version
4.5
On-board graphics card model
Intel UHD Graphics P630
On-board graphics card
Yes
On-board graphics card dynamic frequency (max)
1200 MHz
On-board graphics card base frequency
350 MHz
Discrete graphics card model
Not available
Maximum graphics card memory
128 GB
Power
Thermal Design Power (TDP)
80 W
Technical details
Intel TSX-NI
Yes
Yes
Thermal Monitoring Technologies
Yes
2.0
Intel Trusted Execution Technology
Yes
Yes
Yes
Yes
Yes
Yes
Idle States
Yes
Execute Disable Bit
Yes
Enhanced Intel SpeedStep Technology
Yes
PCI Express slots version
3.0
PCI Express configurations
1x16, 2x8, 1x8+2x4
Supported instruction sets
SSE4.1, SSE4.2, AVX 2.0
Scalability
1S
Intel VT-x with Extended Page Tables (EPT)
Yes
Intel Enhanced Halt State
Yes
Embedded options available
Yes
CPU configuration (max)
1
Processor code
SR3WS
Graphics output
eDP/DP/HDMI/DVI
Product type
Processor
Processor cache
12288 KB
Intel Virtualization Technology for Directed I/O (VT-d)
Yes
Intel 64
Yes
Video decoding
Yes
Thermal Design Power (TDP)
80 W
Supported memory types
DDR4-SDRAM
Yes
Status
Launched
Maximum resolution & refresh rate (VGA)
N/A
Maximum resolution & refresh rate (Integrated Flat Panel)
4096x2304@60Hz
Maximum resolution & refresh rate (HDMI)
4096x2160@24Hz
Maximum resolution & refresh rate (DisplayPort)
4096x2304@60Hz
Market segment
Server
Launch date
Q3'18
Intel Virtualization Technology (VT-x)
Yes
Intel Secure Key Technology version
1.00
Processor cache type
Smart Cache
Bus type units
GT/s
Bus bandwidth
8
Maximum memory
128 GB
Intel TSX-NI version
1.00
Processor brand name
Intel Xeon
Last change
63903513
Product family
Intel Xeon Processors
Maximum graphics card memory
128 GB
Processor ID
0x3E96
Bus speed
8 GT/s
Servicing status
Baseline Servicing
Features
On-board graphics card ID
0x3E96
Maximum number of PCI Express lanes
16
Thermal Design Power (TDP)
80 W
Processor package size
37.5 x 37.5 mm
Processor ARK ID
134860
Thermal Monitoring Technologies
Yes
Idle States
Yes
Execute Disable Bit
Yes
PCI Express slots version
3.0
PCI Express configurations
1x16, 2x8, 1x8+2x4
Supported instruction sets
SSE4.1, SSE4.2, AVX 2.0
Scalability
1S
Embedded options available
Yes
CPU configuration (max)
1
Processor code
SR3WS
Market segment
Server
Harmonized System (HS) code
85423119
Export Control Classification Number (ECCN)
5A992C
Commodity Classification Automated Tracking System (CCATS)
G077159
PCI Express CEM revision
3.0
Processor special features
Intel Clear Video Technology
Yes
Intel Software Guard Extensions (Intel SGX)
Yes
Intel Virtualization Technology for Directed I/O (VT-d)
Yes
Intel 64
Yes
Yes
Yes
Yes
Intel TSX-NI
Yes
Yes
2.0
Intel Trusted Execution Technology
Yes
Yes
Yes
Yes
Yes
Yes
Enhanced Intel SpeedStep Technology
Yes
Intel VT-x with Extended Page Tables (EPT)
Yes
Intel Enhanced Halt State
Yes
Yes
Intel Virtualization Technology (VT-x)
Yes
Intel Secure Key Technology version
1.00
Intel TSX-NI version
1.00
Yes
Yes
4.7 GHz
Yes
Operational conditions
Tjunction
Packaging data
Package width
70 mm
Package depth
116 mm
Package height
101 mm
Package weight
316.1 g
Package type
Box, Tray
Logistics data
Harmonized System (HS) code
85423119
Weight & dimensions
Processor package size
37.5 x 37.5 mm
Package width
70 mm
Package depth
116 mm
Package height
101 mm
Package weight
316.1 g
Other features
Video decoding
Yes
Maximum internal memory
65536 MB
Maximum internal memory
128 GB
CPU configuration (max)
1
Processor code
SR3WS
Graphics output
eDP/DP/HDMI/DVI
