Intel Core Ultra 9 285 processor 36 MB Smart Cache
In Stock
|
£502.63
£603.16 (Inc. VAT)
Intel Core Ultra 9 285 processor 36 MB Smart Cache
Processor
Processor generation
Intel Core Ultra (Series 2)
Processor manufacturer
Intel
Processor codename
Arrow Lake
Processor cache
36 MB
Processor ARK ID
241061
Processor model
285
Processor threads
24
Processor operating modes
64-bit
Processor boost frequency
5.6 GHz
Processor family
Intel Core Ultra 9
Processor cores
24
Box
No
Processor socket
LGA 1851 (Socket V1)
Processor cache type
Smart Cache
Performance cores
8
Efficient cores
16
Performance-core boost frequency
5.4 GHz
Performance-core base frequency
2.5 GHz
Efficient-core boost frequency
4.6 GHz
Efficient-core base frequency
1.9 GHz
Processor base power
65 W
Maximum turbo power
182 W
Maximum number of DMI lanes
8
AI software frameworks supported by CPU
DirectML, OpenVINO, Windows ML, ONNX RT, WebNN
Neural processor unit (NPU)
Neural processor unit (NPU)
Intel AI Boost
Sparsity support
Yes
Windows Studio effects support
Yes
AI software frameworks supported by NPU
DirectML, OpenVINO, Windows ML, ONNX RT, WebNN
Total processor performance up to
36 TOPs
NPU performance up to
13 TOPs
GPU performance up to
8 TOPs
Memory
Maximum internal memory supported by processor
192 GB
Memory types supported by processor
DDR5-SDRAM
Memory clock speeds supported by processor
6400 MHz
Memory channels
Dual-channel
ECC
Yes
Graphics
Discrete graphics card
No
On-board graphics card outputs supported
HDMI 2.1, Embedded DisplayPort (eDP) 1.4b, DisplayPort 2.1
On-board graphics card ID
0x7D67
On-board graphics card refresh rate at maximum resolution (HDMI)
60 Hz
On-board graphics card refresh rate at maximum resolution (DisplayPort)
60 Hz
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)
60 Hz
Number of displays supported (on-board graphics)
4
On-board graphics card DirectX version
12
On-board graphics card OpenGL version
4.5
On-board graphics card model
Intel Graphics
On-board graphics card
Yes
On-board graphics card dynamic frequency (max)
2000 MHz
On-board graphics card base frequency
300 MHz
Discrete graphics card model
Not available
Xe-cores
4
Technical details
Intel® Active Management Technology (Intel® AMT)
Yes
Intel® Secure Key
Yes
Thermal Monitoring Technologies
Yes
Intel® Turbo Boost Technology
2
Intel Trusted Execution Technology
Yes
Intel® Quick Sync Video Technology
Yes
Intel® AES New Instructions (Intel® AES-NI)
Yes
Idle States
Yes
Execute Disable Bit
Yes
Enhanced Intel SpeedStep Technology
Yes
PCI Express slots version
4.0, 5.0
Supported instruction sets
AVX 2.0, SSE4.1, SSE4.2
Scalability
1S
L2 cache
40960 KB
Intel VT-x with Extended Page Tables (EPT)
Yes
Embedded options available
Yes
Graphics output
DP2.1 UHBR20, HDM2.1 FRL 12GHz, eDP1.4b
Intel Virtualization Technology for Directed I/O (VT-d)
Yes
Intel 64
Yes
Status
Launched
Market segment
Desktop
Launch date
Q1'25
Intel Virtualization Technology (VT-x)
Yes
Processor cache type
Smart Cache
OpenCL version
3
Features
On-board graphics card ID
0x7D67
Maximum number of PCI Express lanes
24
Processor ARK ID
241061
Thermal Monitoring Technologies
Yes
Idle States
Yes
Execute Disable Bit
Yes
PCI Express slots version
4.0, 5.0
Supported instruction sets
AVX 2.0, SSE4.1, SSE4.2
Scalability
1S
Embedded options available
Yes
Market segment
Desktop
Use conditions
Workstation, PC/Client/Tablet
Direct Media Interface (DMI) Revision
4
Processor special features
Intel Virtualization Technology for Directed I/O (VT-d)
Yes
Intel 64
Yes
Intel Turbo Boost Max Technology 3.0
Yes
Intel® Speed Shift Technology
Yes
Intel® OS Guard
Yes
Intel® Active Management Technology (Intel® AMT)
Yes
Intel® Secure Key
Yes
Intel® Turbo Boost Technology
2
Intel Trusted Execution Technology
Yes
Intel® Quick Sync Video Technology
Yes
Intel® AES New Instructions (Intel® AES-NI)
Yes
Enhanced Intel SpeedStep Technology
Yes
Intel VT-x with Extended Page Tables (EPT)
Yes
Intel Virtualization Technology (VT-x)
Yes
Intel® Boot Guard
Yes
Intel® Thermal Velocity Boost
Yes
Intel® Volume Management Device (VMD)
Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU
Yes
Mode-based Execute Control (MBE)
Yes
Intel® Turbo Boost Max Technology 3.0 frequency
5.5 GHz
Intel® Thunderbolt 4
Yes
Intel® Thermal Velocity Boost Frequency
5.6 GHz
Intel® Control-flow Enforcement Technology (CET)
Yes
Intel® Thread Director
Yes
Intel® Total Memory Encryption - Multi Key
Yes
Intel® Threat Detection Technology (TDT)
Yes
Intel® Hardware Shield Eligibility
Yes
Intel vPro® Enterprise Platform Eligibility
Yes
Intel® Standard Manageability (ISM)
Yes
Intel® Stable IT Platform Program (SIPP)
Yes
Intel® One-Click Recovery
Yes
Intel® Virtualization Technology with Redirect Protection (VT-rp)
Yes
Intel® Remote Platform Erase (RPE)
Yes
Intel® Deep Learning Boost (Intel® DL Boost) on GPU
Yes
Operational conditions
Maximum operating temperature
105 °C
Other features
Maximum internal memory
192 GB
L2 cache
40960 KB
Graphics output
DP2.1 UHBR20, HDM2.1 FRL 12GHz, eDP1.4b
