AM5 ASUS PRIME X870-P ATX
In Stock
|
£191.96
£230.35 (Inc. VAT)
AM5 ASUS PRIME X870-P ATX
Internal I/O
Number of M.2 (M) slots
4
USB 3.2 Gen 2 (3.1 Gen 2) connectors
1
12V power connector
Yes
Supported storage drive interfaces
M.2, SATA III
USB 2.0 connectors
2
USB 3.2 Gen 1 (3.1 Gen 1) connectors
1
mSATA ports quantity
0
TPM connector
Yes
Number of SATA connectors
0
Number of SATA III connectors
2
Number of SATA II connectors
0
Number of COM connectors
1
Number of chassis fan connectors
4
Front panel audio connector
Yes
EPS power connector (8-pin)
Yes
CPU fan connector
Yes
ATX Power connector (24-pin)
Yes
RGB LED pin header
Yes
Technical details
Motherboard chipset family
AMD
Motherboard chipset
AMD X870
Supported processor sockets
Socket AM5
Parallel processing technology support
Not supported
On-board graphics card
No
HDMI version
2.1
Cooling type
Passive
Back-to-BIOS button
Yes
Motherboard form factor
ATX
Component for
PC
Audio
Audio output channels
7.1 channels
Performance
Number of HDDs supported
2
Supported storage drive types
HDD & SSD
Windows operating systems supported
Windows 10, Windows 11
Motherboard chipset family
AMD
Motherboard chipset
AMD X870
RAID levels
0, 1, 5, 10
Supported processor sockets
Socket AM5
Cooling type
Passive
Audio output channels
7.1 channels
Motherboard form factor
ATX
Component for
PC
Processor
Processor manufacturer
AMD
Compatible processor series
AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
Supported processor sockets
Socket AM5
Processor socket
Socket AM5
Memory
Number of memory slots
4
Memory slots type
DIMM
Supported memory types
DDR5-SDRAM
Memory channels
Dual-channel
Maximum internal memory
192 GB
Unbuffered memory
Yes
Supported memory clock speed (max)
8000 MHz
ECC Ñompatibility
ECC & Non-ECC
Storage controllers
Number of HDDs supported
2
Supported storage drive types
HDD & SSD
Supported storage drive interfaces
M.2, SATA III
RAID levels
0, 1, 5, 10
Number of storage drives supported
6
RAID support
Yes
Graphics
Parallel processing technology support
Not supported
On-board graphics card
No
Rear panel I/O ports
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
3
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
0
DisplayPort version
1.4a
USB 2.0 ports quantity
4
VGA (D-Sub) ports quantity
0
Microphone in
Yes
HDMI version
2.1
HDMI ports quantity
1
Ethernet LAN (RJ-45) ports
1
DVI-D ports quantity
0
USB4 Gen 2x2 ports quantity
2
Line-in
Yes
Network
Ethernet LAN
Yes
Wi-Fi
No
Ethernet interface type
2.5 Gigabit Ethernet
Features
Power source type
ATX
Windows operating systems supported
Windows 10, Windows 11
Motherboard chipset family
AMD
Motherboard chipset
AMD X870
Supported processor sockets
Socket AM5
Cooling type
Passive
Audio output channels
7.1 channels
Motherboard form factor
ATX
Component for
PC
Product colour
Black
Expansion slots
Number of M.2 (M) slots
4
PCI Express x16 (Gen 4.x) slots
2
PCI Express x16 (Gen 5.x) slots
1
BIOS
BIOS type
UEFI AMI
BIOS memory size
256 Mbit
Back-to-BIOS button
Yes
Power
Power source type
ATX
Packaging data
Package width
353 mm
Package depth
273 mm
Package height
68 mm
Package weight
1.5 kg
Software
Windows operating systems supported
Windows 10, Windows 11
Weight & dimensions
Height
48 mm
Package width
353 mm
Package depth
273 mm
Package height
68 mm
Package weight
1.5 kg
Weight
1.44 kg
Width
305 mm
Depth
244 mm
Packaging content
Cables included
SATA
Other features
Height
48 mm
Package width
353 mm
Package depth
273 mm
Package height
68 mm
Package weight
1.5 kg
mSATA ports quantity
0
Weight
1.44 kg
Back-to-BIOS button
Yes
